Y30BH Fe2O3 SrO Ferrite ring Speaker Magnet Parts for sale , Block Magnets Mechanical Equipment

Y30BH Fe2O3 SrO Ferrite ring Speaker Magnet Parts for sale , Block Magnets Mechanical Equipment
Y30BH Fe2O3 SrO Ferrite ring Speaker Magnet Parts for sale , Block Magnets Mechanical Equipment Y30BH Fe2O3 SrO Ferrite ring Speaker Magnet Parts for sale , Block Magnets Mechanical Equipment Y30BH Fe2O3 SrO Ferrite ring Speaker Magnet Parts for sale , Block Magnets Mechanical Equipment

Large Image :  Y30BH Fe2O3 SrO Ferrite ring Speaker Magnet Parts for sale , Block Magnets Mechanical Equipment

Product Details:
Place of Origin: China
Brand Name: STAR
Certification: ISO9001, RoHS, MSDS, Patent certificate, Quality Certificate
Model Number: F24-1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $0.0001~$100.00
Packaging Details: Non-magnetism packing with Iron and foam protection, Export carton and pallet
Delivery Time: 5~15 days as per customer's project and quantity
Payment Terms: T/T, Western Union, MoneyGram, Paypal, L/C, WECHAT
Supply Ability: 500 tons per month

Y30BH Fe2O3 SrO Ferrite ring Speaker Magnet Parts for sale , Block Magnets Mechanical Equipment

Description
Material: SrO, BaO, Fe2O3 Shape: Disc, Ring, Cylinder, Round , Custom Made Specs
Grade: Y30BH Magnetized Direction: Height
OEM/ODM: Yes
High Light:

Fe2O3 Ferrite Block Magnets

,

SrO Ferrite Block Magnets

,

Y30BH Ferrite Permanent Magnets

Y30BH Fe2O3 SrO Ferrite ring Speaker Magnet Parts for sale , Block Magnets Mechanical Equipment

Material: Fe powder, strontium, barium ,etc.



Our Services:

1. Technology support:
When you are not sure what you need, please help provide your product and project details,

our engineers will evaluate and give the best solution to you in short time.


2. Test for customer’s material and magnet performance
We know most of customers have not much professional equipment for their magnet testing,

But do not worry, we can free of charge help you test if it is true.

When you buy magnets with a very lower price, or you think something is not good when use the magnets,

you can ask us for help, we will do the professional testing and let you know what you get.

3. Fast and safety shipping
We have worked with some experienced Express courier and Sea shipper more than 13 years,

we can guarantee every process of your magnet order from materials, design, production, testing to delivery, we really do all care.

4. Suggestions and Comments
We love customers and love to hear from you whether it's feedback or questions

about our Quality, Service, Market, etc, we will continue improving our performance and together we are stronger.


Mat.

                  Br                 bHc                 iHc           BHmax
mT KG KA/m KOe KA/m KOe KJ/m³ MGOe
Y10T 200~235 2.0~2.35 125~160 1.57~2.01 210~280 2.64~3.52 6.5~9.5 0.8~1.2
Y20 320~380 3.2~3.8 135~190 1.70~2.38 140~195 1.76~2.45 18.0~22.0 2.3~2.8
Y22H 310~360 3.1~3.6 220~250 2.77~3.14 280~320 3.52~4.02 20.0~24.0 2.5~3.0
Y23 320~370 3.2~3.7 170~190 2.14~2.38 190~230 2.39~2.89 20.0~25.5 2.5~3.2
Y25 360~400 3.6~4.0 135~170 1.70~2.14 140~200 1.76~2.51 22.5~28.0 2.8~3.5
Y26H 360~390 3.6~3.9 220~250 2.77~3.14 225~255 2.83~3.21 23.0~28.0 2.9~3.5
Y27H 370~400 3.7~4.0 205~250 2.58~3.14 210~255 2.64~3.21 25.0~29.0 3.1~3.7
Y30 370~400 3.7~4.0 175~210 2.20~2.64 180~220 2.26~2.77 26.0~30.0 3.3~3.8
Y30BH 380~390 3.8~3.9 223~235 2.80~2.95 231~245 2.90~3.08 27.0~30.0 3.4~3.7
Y30H-1 380~400 3.8~4.0 230~275 2.89~3.46 235~290 2.95~3.65 27.0~32.0 3.4~4.0
Y30H-2 395~415 3.95~4.15 275~300 3.46~3.77 310~335 3.90~4.21 28.5~32.5 3.5~4.0
Y32 400~420 4.0~4.2 160~190 2.01~2.38 165~195 2.07~2.45 30.0~33.5 3.8~4.2
Y33 410~430 4.1~4.3 220~250 2.77~3.14 225~255 2.83~3.21 31.5~35.0 4.0~4.4
Y35 400~410 4.0~4.1 175~195 2.20~2.45 180~200 2.26~2.51 30.0~32.0 3.8~4.0


Our Magnet application:

Ferrite magnets are widely used in motors, sensors, loudspeakers, holding-magnet system, magnetic couplings, magnetic therapy, toys, etc.

a) Electro-acoustic field: such as loudspeaker, headphone, earphone, stage sound device, alarm, microphone and so on.
Because of good performance, our magnets can provide sound equipment better sensitiveness and susceptibility.

b) Electric products: Permanent magnetic actuator vacuum circuit breaker, magnetic latching relay, watt-hour meter, water meter, sensor, reed switch and so on.

c) Motor areas: VCM, CDVD-ROM, generator, electromotor, servo motor, vibration motor, step motor, DC motor, linear motor and so on.
Our magnets with stable performance and high HCJ can work under high temperature which can guarantee your products work better.

d) mechanical equipment: magnetic separator, magnetic holder, and other magnetic machines.

e) Health care: nuclear magnetic resonance spectrometer, medical apparatus and instruments, magnetic therapy and health care products, fuel-saving magnetizer and so on. Our stable permanent magnets used in health care areas will make people healthier.

f) Other fields: bags magnets, toy magnets, craft gifts and packaging, doors and windows magnets, magnetic locks, magnetic holding devices and so on.

 Apply for Other Area

Y30BH Fe2O3 SrO Ferrite ring Speaker Magnet Parts for sale , Block Magnets Mechanical Equipment 0
