24 Bay Server Case Hot Swap, 4U Rackmount Server Case With 24 Hot-Swappable SATA/SAS Drive Bays

24 Bay Server Case Hot Swap, 4U Rackmount Server Case With 24 Hot-Swappable SATA/SAS Drive Bays
24 Bay Server Case Hot Swap, 4U Rackmount Server Case With 24 Hot-Swappable SATA/SAS Drive Bays 24 Bay Server Case Hot Swap, 4U Rackmount Server Case With 24 Hot-Swappable SATA/SAS Drive Bays 24 Bay Server Case Hot Swap, 4U Rackmount Server Case With 24 Hot-Swappable SATA/SAS Drive Bays

Large Image :  24 Bay Server Case Hot Swap, 4U Rackmount Server Case With 24 Hot-Swappable SATA/SAS Drive Bays

Product Details:
Place of Origin: China
Brand Name: OEM
Model Number: 4324
Payment & Shipping Terms:
Minimum Order Quantity: 10
Packaging Details: Single pack: 540*380*42mm, Carton pack(4pcs):570*195*410mm, Single gross weight: 5kg, G.W. of carton: 21KG
Delivery Time: 8-15 workdays
Payment Terms: T/T
Supply Ability: 50000 per week

24 Bay Server Case Hot Swap, 4U Rackmount Server Case With 24 Hot-Swappable SATA/SAS Drive Bays

Description
Product Name: 4U Rackmount Server Case Product Size: 483mm X 650mm X 176mm
Motherboard Support: Support EEB (12"x13"), CEB(12"x10.5"), ATX (12"x9.6"), Micro ATX (9.6" X 9.6") Drive Bay: 24×hot Swap SATA/ SAS 6G Hard Drive Bay
Cooling Fan: 4 X 80mm Middle Wind Wall, 2 X 80mm Back Board Fan Switch: Power Switch X 1, System Reboot X 1
Fans Support: 12CM*8 Cooling Storm Fans Indicator Light: Power Switch X 1, Hard Drive X 1, Network X 2
Package: Sigle Package/double Package Weight (no Hard Drive): 18 Kg(N.W.) 21.(G.W.)
High Light:

4U 24 Bay Server Case

,

4U Rackmount Server Case

,

Length 483mm 4U Server Case

24 bay server case hot swap, 4U rackmount server case with 24 Hot-Swappable SATA/SAS Drive Bays



24 bay server case hot swap, 4U rackmount server case, server case with 24 Hot-Swappable SATA/SAS Drive Bays



The Chia platform was created by a company called Chia Network, which saw a valuation of $500 million in a recent investment round, and claims to be aiming for an IPO before the end of 2021.



Speciafication:



Drive bay 24×hot swap SATA/ SAS 6G hard drive bay
Cooling fan 4 x 80mm middle wind wall, 2 x 80mm back board fan
switch power switch x 1, system reboot x 1
Indicator light power switch x 1, hard drive x 1, network X 2
interface 2 front board USB port, 6 inner SFF-8087 Mini SAS port, 12个 4-pin Redundant power interface
Motherboard compatibility support EEB (12"x13"), CEB(12"x10.5"), ATX (12"x9.6"), Micro ATX (9.6" x 9.6")
Optional power supply standard ATX power, Mini Redundant power (H x W 5.91x3.39 inch)
Size (width x depth x height) (483mm x 650mm x 176mm)
package sigle package/double package
Weight (no hard drive) 18 kg(N.W.) 21.(G.W.)
Ambient temperature 0/40,32/104°F(Working)-20/60Ç,-4/140(non-working)
Relative humidity 5% to 95%, Non-condensing



Features

1 • 4U rack design
2 • 24X hot-swap SATA / SAS 6G hard drive bays
3 • Six internal SFF-8087 mini-SAS cable supports up to twenty four 3.5 "or 2.5" SATA (I or II) or SAS hard disk;
4 • The backplane is well ventilated with a horizontal installation
5 • The LED indicator shows the power and operating status of each hard disk drive
6 • Supports EEB (12 "x13"), CEB (12 "x10.5"), ATX (12 "x9.6"), MICRO ATX (9.6 "x 9.6")
7 • Complies with EU RoHS regulations
8 • Redundant 4-pin Molex power connector supports redundant power supplies
9 • Two front USB ports
10 • Smooth border prevents scratching your skin



24 Bay Server Case Hot Swap, 4U Rackmount Server Case With 24 Hot-Swappable SATA/SAS Drive Bays 024 Bay Server Case Hot Swap, 4U Rackmount Server Case With 24 Hot-Swappable SATA/SAS Drive Bays 1

24 Bay Server Case Hot Swap, 4U Rackmount Server Case With 24 Hot-Swappable SATA/SAS Drive Bays 2
